Custom MMIC在提供多個頻率和功率級別的功率放大器(PA)解決方案方面有著良好的記錄。Custom MMIC的PA支持對移動應用程序、商業基礎設施以及各種軍事和空間系統提出苛刻的系統要求。Custom MMIC功率放大器技術和產品繼續使客戶能夠改進尺寸、重量和功率(SWAP)，并提高下一代的性能。
Custom MMIC功率放大器的主要特性
從DC到W波段的頻率覆蓋
特定于應用的產品焦點(如功率或線性)
不同的功率水平和高的PAE和增益性能
優秀的熱管理
小尺寸包裝
Custom MMIC功率放大器的典型應用
軍用和商業雷達
軍事和商業衛星通信
基礎設施通信鏈路
儀器和器具
行波管放大器(TWTA)的替代品
深圳市立維創展科技是Custom MMIC的經銷商，立維創展協助選取滿足需求的最合適的MMIC優化微波射頻射頻信號鏈。Custom MMIC是一個完整性的ISO認證和同類型絕佳MMICs經銷商。供應迅速增長的高性能射頻/微波射頻MMIC產品系列。
