ADI同步采樣ADC
發布時間：2022-07-26 16:25:12 瀏覽：5798
ADI同步采樣精密模數轉換器在單封裝中供應2-8個分立ADC，兼容2-12個通道，分辨率的范圍為kSPS至5MSPS。ADI同步精密轉換器供應行業領先的噪音、線性和動態范圍性能，以滿足用戶的速率、功能損耗和規格要求。ADI采用同步采樣ADC，用戶能夠同一時間轉化數個數據信號并保存相位信息內容。ADI提供一系列ADC兼容單端、差分和偽差分輸入設計的構架，具體包括
? SAR—逐次逼近型ADC
? Σ-Δ型調制器
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://www.ckk6s.cn/brand/25.html
產品型號 | Channels | Resolution | Sample Rate (max) | ADC SNR in dBFS (typ) | INL in LSB (typ) | Power (typ) |
|
| bits | SPS | dBFS | LSBs | W |
AD4630-16 | 2 | 16 | 2M | 97.4 | 0.07 |
|
AD4630-24 | 2 | 24 | 2M | 105.7 | 1.6 | 30m |
AD7380-4 | 4 | 16 | 4M | 91 | 2 | 83m |
AD7381-4 | 4 | 14 | 4M | 85.3 | 0.4 | 83m |
AD7389-4 | 4 | 16 | 2M | 90.5 | 0.1 | 83m |
AD4134 | 4 | 24 | 1.496M | 107 |
| 125m |
AD7606C-16 | 8 | 16 | 1M | 92 | 0.5 | 47m |
AD4680 | 2 | 16 | 1M | 92.5 | 0.7 | 29.4m |
AD4681 | 2 | 16 | 500k | 92.5 | 0.7 | 18.7m |
AD4682 | 2 | 16 | 1M | 87.5 | 1 | 29m |
AD4683 | 2 | 16 | 500k | 87.5 | 1 | 29.4m |
AD7606C-18 | 8 | 18 | 1M | 93 | 2 | 245m |
AD7383 | 2 | 16 | 4M | 86.1 | 1 | 87m |
AD7384 | 2 | 14 | 4M | 84.1 | 0.4 | 84m |
AD7134 | 4 | 24 | 1.5M | 107 |
| 504m |
AD7386 | 4 | 16 | 4M | 87.5 | 1.5 | 83m |
AD7387 | 4 | 14 | 4M | 84 | 0.5 | 81m |
AD7388 | 4 | 12 | 4M | 73.8 | 0.2 | 80m |
AD7606B | 8 | 16 | 800k | 89.5 | 1.16 | 40m |
AD7380 | 2 | 16 | 4M | 92.5 | 0.75 | 83m |
AD7381 | 2 | 14 | 4M | 85.4 | 0.3 | 83m |
LTC2353-16 | 2 | 16 | 550k | 94.2 | 0.3 | 162m |
LTC2357-16 | 4 | 16 | 350k | 94.2 | 0.3 | 175m |
LTC2357-18 | 4 | 18 | 350k | 96.4 | 1 | 174m |
AD7616-P | 16 | 16 | 1M | 90.5 | 1 | 230m |
AD7617 | 16 | 14 | 1M | 85 | 0.3 | 230m |
AD7771 | 8 | 24 | 128k | 95 | 1.5 | 133m |
LTC2324-12 | 4 | 12 | 2M | 78.5 | 0 | 102m |
LTC2324-14 | 4 | 14 | 2M | 82 | 1 | 102m |
LTC2324-16 | 4 | 16 | 2M | 82 | 2 | 102m |
LTC2325-12 | 4 | 12 | 5M | 77 | 0.5 | 102m |
LTC2325-14 | 4 | 14 | 5M | 82 | 1 | 102m |
LTC2320-12 | 8 | 12 | 1.5M | 77 | 0.25 | 102m |
LTC2320-14 | 8 | 14 | 1.5M | 81 | 1 | 102m |
LTC2325-16 | 4 | 16 | 5M | 82 | 2 | 102m |
LTC2358-18 | 8 | 18 | 200k | 96.4 | 1 | 219m |
LTC2353-18 | 2 | 18 | 550k | 96.4 | 1 | 187m |
LTC2358-16 | 8 | 16 | 200k | 94.2 | 0.3 | 219m |
AD7605-4 | 4 | 16 | 300k | 90 | 0.5 | 71m |
AD7616 | 16 | 16 | 1M | 90.5 | 1 | 230m |
