0.1 pf thru 1.9 pf

.010" x .010" x .005"

810R1 thru 811R9

2.0 pf thru 9.9 pf

.015" x .015" x .005"

812R0 thru 819R9

10.0 pf thru 29.0 pf

.020" x .020" x.006"

8110R thru 8129R

30.0 pf thru 49.0 pf

.030" x .030" x.006"

8130R thru 8149R

50.0 pf thru 99.0 pf

.040" x .040" x .008"

8150R thru 8199R

100 pf thru 199 pf

.050" x .050" x .008"

81100 thru 81199

200 pf thru 399 pf

.070" x .070" x.008"

81200 thru 81399

2.0 pf thru 9.9 pf

.010" x .010" x .005"

802R0 thru 809R9

10.0 pf thru 29.0 pf

.015" x .015" x .005"

8010R thru 8029R

30.0 pf thru 49.0 pf

.020" x .020" x.006"

8030R thru 8049R

50.0 pf thru 99.0 pf

.030" x .030" x.006"

8050R thru 8099R

100 pf thru 199 pf

.040" x .040" x .008"

80100 thru 80199

200 pf thru 399 pf

.050" x .050" x .008"

80200 thru 80399

400 pf thru 600 pf

.070" x .070" x.008"

80400 thru 80600

A = .05 pF

G = 2%

B = .1 pF

J = 5%

C = .25 pF

K = 10%

D = .5 pF

M = 20%

F = 1%

Standard Tolerance is +10%

Parameters

Rating

Operating Temperature

-55° C to +150° C

Storage Temperature

-65° C to +200° C

Temperature Coefficient

190 ppm/°C Max
40 ppm/°C typical

Voltage Breakdown

Varies according
