General Specifications

Lab Flex@065T

Lab Flex@100T

Lab-Flex@160T

Lab Flex 200T

Diamete

0.056

0.1

0.15

0.189

Frequency,Max (GHz)

50

50

40

31

Loss @5 GHz(dB/100ft)

69.0

41.8

25.5

16.3

Electrical Specifications

Lab Flex@065T

Lab Flex@100T

Lab-Flex@160T

Lab Flex 200T

Impedance,Nominal  (Ω)

50

50

50

50

Velocity of Propagation (%)

78.7

80

80.3

84

Shielding Effectiveness,18 GHz(dB/t)

>-100dB

>-100dB

>-90dB

>-90dB

Capacitace (pF/ft

25.8

25.4

25.3

23.8

Delay (ns/ft)

1.29

1.27

1.27

1.2

Mechanical Specifications

Lab Flex@065T

Lab Flex@100T

Lab-Flex@160T

Lab Flex 200T

Weight (lbs/100ft)

0.95

1.4

3.1

3.4

Temperature Range (C)

-65 to +150*

-65 to +150*

-65 to +200*

-65 to +200*

Minimum Bend Radius (inches

0.25

0.35

0.5

1.1

Construction Data

Lab Flex@065T

Lab Flex@100T

Lab-Flex@160T

Lab Flex 200T

Inner Conductor

Solid SPc

Solid SPc

Solid SPc

Solid SPC

Dielectric

Foamed PTFE

Foamed PTFE

Foamed PTEF

Extruded PTFE

First Outer Shield

SPC Flat Spira

SPC Flat Spira

SPC Flat Braid

SPC Flat Braid

Second Outer Shield

SPC Round Braid

SPC Round Braid

SPC Round Braid

SPC Round Braid

Jacket

FEP

FEP

FEP

FEP
