?RLC Electronics寬帶肖特基和隧道二極管探測器
發布時間：2024-12-11 17:24:10 瀏覽：466
RLC Electronics寬帶肖特基和隧道二極管探測器通常用于同軸系統，在10 MHz至18.0 GHz的頻率范圍內檢測高至100 mW的相應微波功率。RLC Electronics寬帶肖特基和隧道二極管探測器保障了平整的頻率響應和高靈敏度。適用的選項包含負極性輸出、正極性輸出、匹配和平方律響應。
深圳市立維創展科技有限公司授權代理銷售RCL產品，如若需要RLC Electronics微波，歡迎點擊右側客服咨詢！！！
Schottly Diode Specifications
Model No. | CR-133 | CR-183 |
Frequency Range: (MHz) | 10 - 12,400 | 10 - 18,000 |
Frequency Response: *
| ±0.2 dB/octave to 8 GHz ±0.5 dB/full range | ±0.2dB/octave to 8 GHz ±0.5dB to 12.4 GHz ±1.0dB to 18 GHz |
Sensitivity: (Typ.) High Low | 100 mV output at 0.35 mW 0.4 mV output/uW |
Power: (Max.) | 100 mW (peak or average) |
Output Impedance | 15k ohms max. shunted to 10 pf |
VSWR: 10 MHz to 4.5 GHz 4.5 GHz to 7.0 GHz 7.0 GHz to 12.4 GHz 12.4 GHz to 18 GHz | 1.20 max. 1.35 max. 1.50 max. 1.70 max. |
Polarity: | Negative |
Options
Model No. | Feature |
CR-133M CR-183M
| Matched pair of CR-133’s or CR-183’s Tracking (Max.): ±0.2 dB to 8 GHz ±0.3 dB from 8 to 12.4 GHz ±0.5 dB from 12.4 to 18 GHz |
CR-134 CR-184 | CR-133 or CR-183 With positive output polarity |
CR-135 CR-185
| CR-133 or CR-183 With Square Law load ±0.5 dB max. variation from Square Law up to 50 mV output into 75k min. Sensitivity (Min.): 0.1 mV DC/uWcw |
Tunnel Diode Specifications
CRT–1–2
Model No. | Frequency Range (GHz) | Frequency Response (dB Max.) | VSWR (Max.) | Output (mV Min.) | DC blocks | Power (Max.) | Polarity |
CRT-218 | 2 - 18 | ±1.0 | 3.5:1 | 1.8 | Not Available | 100 mW | Negative |
CRT-625 | 5.8 - 6.7 | ±.15 | 2.0:1 | 2.0 | Optional |
CRT-1425 | 13.7 - 14.8 | ±.20 | 2.0:1 | 2.0 | Optional |
CRT-1785 | 17.3 - 18.4 | ±.25 | 2.0:1 | 2.0 | Optional |
