產(chǎn)品詳情介紹
| Part Number | Input Voltage | Output Voltage | Output Current | No load Input Current | Efficiency (%) | I/O Isolation Voltage |
| CHB300-300S05 | 180~425V | 5V | 60A | 10mA | 89 | 3000VAC |
| CHB300-300S12 | 180~425V | 12V | 25A | 10mA | 88 | 3000VAC |
| CHB300-300S24 | 180~425V | 24V | 12.5A | 10mA | 90 | 3000VAC |
| CHB300-300S28 | 180~425V | 28V | 10.7A | 10mA | 90 | 3000VAC |
| CHB300-300S48 | 180~425V | 48V | 6.25A | 10mA | 90 | 3000VAC |
| CHB300-300S05N | 180~425V | 5V | 60A | 10mA | 89 | 3000VAC |
| CHB300-300S12N | 180~425V | 12V | 25A | 10mA | 88 | 3000VAC |
| CHB300-300S24N | 180~425V | 24V | 12.5A | 10mA | 90 | 3000VAC |
| CHB300-300S28N | 180~425V | 28V | 10.7A | 10mA | 90 | 3000VAC |
| CHB300-300S48N | 180~425V | 48V | 6.25A | 10mA | 90 | 3000VAC |
同時CINCON 還提供600W 、750W的DC-DC高壓輸入電源模塊產(chǎn)品，CFB600-300S CFB750-300S系列。
